cnc horizontal Oscillating saw

Model:CNC-2100AH



Application :
Automotive industry, upholstery and furniture industry, mattresses and packing industry

Material to cut :
HR + CMHR, PUR soft foam, visco, latex, basotect , rebond foam, frame foam, Polyethylen

Description:
the two crossing-saw contour cutting , which is the most up-dated contour cutting machine developped by us in the world ,it can cut with two oscillating saw ;vertical saw ,horizontal saw one after one , the machine adopts the world most advanced technical skills .it's characteristics can be described as following :

Cutting precision
Exact angles, very sharp edges, extremly small radii

Customer Requirements:
﹞High quality standard, great stability of value, qualified and quick service
﹞Quick knife changing possible: max :3 min
﹞Low knife costs
﹞No foam disortion caused by the oszillating motion

cnc horizontal Oscillating saw)

weight:

1.8ton

knife data (mm) :

(2345)*3*0.5

power :

8kw ,380v.50HZ

cutting speed (m/min)

0~6.3m/min

machine size (mm):

6000*3000*2300

minimun cutting radii

10mm

CNC type:

industry PC

cutting tolerance

㊣ 0.5mm

operation system :

widows 2000 or above

cuttiing material size

2200*2200*1200mm
