foam cutting with belt convey

Model : HHHS-V/0V (with vacuum)





Description :
The Automatic horizontal Splitting and Stacking Machine is used to split flexible PU foam blocks into thin layers( can be set as you want ) in a highly efficient and economic way. The cut sheets remain lying on the block and are stacked one onto another. This allows for an automatic and unattended cutting procedure of the machine. the machine equip with vacuum which is more accurately , especially , for light foam cutting , the vacuum can be acted as hold down device, it's characteristics can be described as following :
﹞belt conveyor bring easy handle of block
﹞with hold-down device press roller ( it's automatic press down when cutting sheet by sheet )
﹞Controlled by PLC and all cutting data can be set in the box.
﹞with one-edge cutting
﹞blade covering box printed with special materials decreasing the friction wastage between the blade and blade cover
﹞Grinding unit & Grinding dust extraction unit

HORIZONTAL SPLITTING

technical data

HHHS-V

HHHS-0V

customer-built

max cutting height

1200mm

cutting width and length

1650W*2000L/2150W*3000L

total power

11.74kw

11.74kw

slice thinkness

1MM~150mm

1~150mm

cutting tolerance

+/-0.1mm( accoding to the nature of the materials )with tolerance adjusted function

blade knife length

8940mm/10000mm

cutting tool options

blade knife

blade knife

machine size

L5000*W4000*H2500

L7000*W4500*H2500
