foam slabline horizontal splitting (foam roller)
Model: EFLS- 1650/2150
DESCRIPTION
The thin foils horizontal Splitting Machine is used to split long flexible PU foam blocks into thin layers( can be set as you want ) in a highly efficient and economic way. the cutting frame run along with the long block base concrete or sandy wood table . One operator need when cutting , as it's need to hold the sheet winding roller ,the operating process is simple and easy to handle ,
it's characteristics can be described as following :
·with hold-down device press roller
·controlled with electronic box and all cutting data can be set in the box .
·with one-edge cutting
·blade covering box printed with speciall materials decreasing the friction wastage between the blade and blade cover
·Grinding unit
·Grinding dust extraction unit
technical data |
EFLS- 1650 |
EFLS- 2150 |
custome
r-built |
max cutting height |
1200mm |
1200mm |
cutting width |
1650 |
2150 |
total power |
6.42kw |
7.12kw |
slice thinkness |
1MM~60mm |
1~60mm |
cutting tolerance |
±0.1mm( according to the nature of
the materials ) |
blade knife length |
6780mm |
8300mm |
machine size |
L3550*W2640*H2350mm |
L4050*W2640*H2350mm |
|
