Tape Edge Machine

Model:HHQT-B2

Tape Edge Machine

Features:
1) Adopts advanced chainstitch sewing heads
2) Auto-lifting table and hand-controlled tilting of sewing heads
3) Various speeds for moving carriage and sewing and auto-slowdown at corners
4) Straight, even and trim seam
5) Stainless steel table top
6) Equipped with level-adjusted device
7) Low noise, small vibration and stable performance
8) Thickness of mattress: 70 - 280mm?
9) Table lifting range: 140mm?
10) Tilting angle: 35 - 55∼
11) Table sizes: 1,870 x 1,320mm?
12) Overall dimensions: 2,380 x 1,400 x 1,650mm?
13) Total power: 1.2kW?
14) Total weight: 425kg

Foam mattress seal packing machine

Model:HHFP--60T



Description:
This machine is mostly used for large foam or mattress reducing capacity after pressing it in order to transport more conveniently

Technical data :
Oil pressure max: 60ton
Slice electricity temperature max: 200 C
Machine weight: 5000kg
Foam capacity max: L2100*W2000*H500mm
Treading distance max: 600mm
Machine external size: L10000*W 3000*H3500mm
