Circle foam cutting

Model:EFRC-6/7/10 Carrousel splitting machine (flexible & rebond foam density below 100kg/m3)

Model:HHRC-RT-6/7/10 Carrousel splitting machine ( rebond foam density within 300kg/m3)


Application Area:
Furniture industry, mattress industry, automobile industry, packing industry, medicine industry.

Description:
The Automatic Circular Splitting and Stacking Machine is used to split flexible PU foam blocks into thin layers in a highly efficient and economic way. The cut sheets remain lying on the block and are stacked one onto another. This allows for an automatic and unattended cutting procedure of the machine. A substantial increase of capacity compared with the horizontal cutting machines equipped with sliding table can be achieved, since due to the rotating circular table, the return stroke after each cut is eliminated.

cutting block pcs :
cutting block pcs :
HHRC-RT-6
BLOCK SIZE OF (W1.5℅L2℅H1.2)℅4 PCS
HHRC-RT-7
BLOCK SIZE OF (W1.5℅L2℅H1.2) ℅5 PCS Or BLOCK SIZE OF (W2.15℅L3℅H1.2)℅3 PCS
HHRC-RT-10
BLOCK SIZE OF (W1.5℅L2℅H1.2)℅8 PCS Or BLOCK SIZE OF (W2.15℅L4.5℅H1.2)℅3 PCS

specification data ( mm/")

HHRC-6

HHRC-7

HHRC-10

table size dia-meter 6000mm 7000mm 10000mm

total power

7.94kw

8.74kw

10.2 kw

worktable rotating speed

0~3.5r/min

0~3.5r/min

0~3.5r/min

Knife blade length

8940mm

10000mm

10240mm

cutting thickness

1mm~

1mm~

1mm~

Cutting tolerance

㊣0,1 mm

with tolerance adjusted function



optional

vacuum
