high-precision horizonal splitting- with stationary working table

Model: HHHS-1650

HP/2150HPㄗwith vacuum)



Material to cut :
flexible foam , semi-rubber, materials used in the areas such as , cosmetic and electronic products

Description :
this machine created by us to cater to some special areas ,such as ,materials of hi-soft foam apply to cosmetic and areas as electronic products which need high accurate cutting ,however, you can also used to cut some common flexible foam , and high-density semi-rubber materials and the cutting thickness can arrive at 1mm .compared with our other horizontal splitting machine , this one take advantage table immobility and cutting frame moving along the table which equip with vacuum under the table insuring high-accurate cutting performance
﹞with hold-down device press roller and vacuum is optional
﹞Controlled with PLC programming and all cutting data can be set in the electronic box.
﹞with one-edge cutting
﹞blade covering box printed with special materials decreasing the friction wastage between the blade and blade cover
﹞Grinding unit
﹞Grinding dust extraction unit
﹞table can be extend as long as you want

specification data ( mm/")

HHHS-1250HP

HHHS-1650HP

HHHS-

2150HP

total power

9.44kw

9.44kw

11.62kw

cutting frame speed

0~15m/min

0~15m/min

0~15m/min

blade length

6420mm

7300mm

8300mm

cutting thinkness

1~60mm

1~60mm

1~60mm

Cutting tolerance

㊣0,1 mm

options

vacuum



model: HHHS-1250HP (wih vacuum)

Main Use:
This machine adopts advanced inverter timing and PLC programs controlled techniques. fixed with powerful induction fan and pulled by metal strip. Its running is reposeful and cutting is accurate. This machine also can be settled for high-precision electronic foam slices(Min slices tolerance of 0.1)
Major Technical Specification :

Rubber's cutting size L1000*W800*H600mm
Running Speed 0-15m/min
Motor Power 9.29kw
Cutting Thickness 1mm-60mm
Cutter Perimeter 5860mm
External size (L*W*H) L5000*W2900*2600mm
